Mid-Wheel Manoeuvrability with Individual Seating Options
The Quantum Edge 3 combines a responsive mid-wheel-drive powerchair base with seating and control options designed around the individual user.
- A smoother everyday ride: SRS — Smooth Ride Suspension — helps cushion the movement of the chair over suitable everyday surfaces.
- Positioning to suit your needs: TRU-Balance 3 configurations offer static seating or selected powered functions, including tilt, recline and leg-support adjustment.
- Optional height adjustment: iLevel can raise the seat by up to 305mm, helping with access to higher surfaces and conversations at eye level.
The final setup determines the chair’s speed, dimensions, controls and powered functions. Speak to Modern Mobility about your seating, transfers, usual surroundings and transport requirements before choosing a configuration.
Quantum Edge 3 Features
- Mid-wheel-drive base for responsive everyday manoeuvring
- SRS — Smooth Ride Suspension
- Configurable TRU-Balance 3 seating
- Optional iLevel seat elevation of up to 305mm
- Powered tilt, recline and leg-support options
- Front and rear LED fender lights
- Choice of joystick, attendant and specialist control options
- Maximum published user capacity of 136kg
- Choice of shroud colours and drive-wheel accents

| Manufacturer | Quantum Rehab |
| Drive Configuration | Mid-wheel drive |
| Maximum User Weight* | 136kg / 21 stone 6lb |
| Speed Packages* | 4mph standard manufacturer package; selected 6mph and 7mph options available |
| Suspension | SRS — Smooth Ride Suspension |
| Turning Radius* | Approximately 521mm / 52.1cm |
| Base Length* | Approximately 820mm / 82cm, without front riggings |
| Base Width* | Approximately 620mm / 62cm with standard drive wheels; approximately 671mm / 67.1cm with knobby wheels |
| Complete Chair Dimensions* | Depend on seating, armrests, controls and leg supports; confirm the configured measurements |
| Ground Clearance* | Approximately 69mm at the battery tray |
| Drive Wheels | 14-inch; tyre options depend on configuration |
| Front and Rear Castors | 6-inch |
| Base Weight* | Approximately 63kg; excludes the complete seating and battery configuration |
| Batteries* | Two 12V 62Ah deep-cycle batteries in the published UK configuration |
| Battery Weight* | Technical sheet reference: approximately 17.24kg each; varies by battery supplied |
| Charger | 8A off-board charger |
| Braking | Electronic regenerative braking and parking brake |
| Optional iLevel | Up to 305mm / 12 inches of powered seat elevation |
| Driving with iLevel Raised* | Reduced maximum speed; confirm the limit for the selected configuration |
| Controls | Controller and alternative-control options depend on the selected package |
| Lighting | LED fender lights; road-use lights and indicators depend on the selected package |
| USB Charging | USB charging port |
Seating Sizes and Seat Heights
The following figures describe published TRU-Balance 3 configurations. Not every combination of seating, supports and powered functions is available in every size.
| Seating Configuration | Width and Depth Range | Seat Pan to Floor Height |
|---|---|---|
| Static Seating | 12–22 inches / approximately 305–559mm | 16.5–18.5 inches / approximately 419–470mm |
| Powered Tilt | 12–22 inches / approximately 305–559mm | 17.5–19.5 inches / approximately 445–495mm |
| Powered Tilt with iLevel | 12–22 inches / approximately 305–559mm | 17.5–19.5 inches / approximately 445–495mm, before elevation |
Seat-height figures are measured from the seat pan and do not include cushion thickness. Available heights and dimensions depend on the chosen components. Confirm the final sitting height and transfer requirements during configuration.
*Manufacturer reference figures. Performance, capacity, weight and dimensions vary with the selected equipment and operating conditions. The 63kg base weight is not the complete chair weight. Optional powered functions and higher-speed packages are not automatically included in the advertised starting price.
A Powerchair Configured Around Your Routine
The Edge 3 is worth considering when everyday mobility needs to work alongside more individual seating, positioning or control requirements.
Compare our complex powerchairs if you need to explore different seating systems, drive bases or control arrangements.
Discuss before choosing: Your seating needs, control access, transfer method, usual journeys and transport arrangements. Ask for an itemised quote showing exactly which equipment and powered functions are included.
Check the Complete Chair Against Your Surroundings
Base dimensions are useful for comparison, but seating, armrests, controls and leg supports determine how the finished Edge 3 fits into your daily environment.
Doorways & Furniture
Measure narrow entrances, corridors and lifts. Check room to turn and approach desks, tables and transfer surfaces with your selected seating and foot supports.
Outdoor Use & iLevel
Plan suitable routes and follow the supplied operating guidance. Raised-seat driving is restricted to appropriate flat, level surfaces and the permitted speed for your configuration.
Vehicle Loading
Obtain the complete chair’s weight before choosing a ramp or lift. The published 63kg base weight does not include the full seating, battery and accessory setup.
Charging & Storage
Provide a dry storage area with suitable mains access and space to approach the charging socket. Follow the instructions for the batteries and charger supplied.
Occupied Vehicle Transport
If you need to remain seated during vehicle travel, confirm that the exact powerchair and seating configuration are approved for occupied transport. The appropriate securement points, wheelchair restraints and occupant restraints must be used according to the supplied instructions. A general crash-tested claim does not establish suitability for every configuration.

Quantum Edge 3 Mid-Wheel Powerchair
The Edge 3 offers SRS (Smooth Ride Suspension), giving a smooth, comfortable ride and advanced stability. Optional iLevel® is available at 4.5 mph with up to 12” of power-adjustable seat height.Optional Extras
We have a range of accessories and optional specialty equipment designed to make your powerchair more unique and custom to you and your needs
iLevel®
iLevel technology is designed to improve the daily functionality and quality of life. Ilevel allows the powerchair seat to be fully elevated while at walking speed (7.2 kmh/4.5mph) . iLevel’s patented Extra Stability Technology® enhances safety for transfers, reach, and numerous other activities of daily living. The Ilevel feature allows you to elevate and descend whilst on the move illimating the inconvenience of a stop start journey.
TRU-Balance 3
TRU-Balance 3 Power Positioning Systems feature an innovative design that maximises functional independence while providing an appealing look and feel. TRU-Balance 3 has the ability for quick and easy fine-tuning adjustments to ensure maximum comfort and positioning. Available configurations include power tilt, power recline, power articulating foot platform, and static seating.
Quantum Edge 3 Powerchair FAQs
Answers to common questions about Edge 3 configurations, iLevel, seating, dimensions, weight, batteries and transport.
iLevel is optional and should be specified in your quotation. The advertised starting price applies to the standard configuration rather than every powered function shown or described.
The Edge 3’s optional iLevel system provides up to 305mm, or 12 inches, of powered seat elevation.
Compatible configurations permit raised-seat driving at a reduced maximum speed. Confirm the limit for your selected setup and follow the instructions restricting use to appropriate flat, level surfaces.
The manufacturer’s UK range includes 4mph, 6mph and 7mph packages. The speed supplied depends on the selected motors, programming and equipment; confirm it in your quotation.
The published base width is approximately 620mm with standard drive wheels, increasing with some wheel options. Armrests, controls and seating can affect the complete width, so obtain the configured measurements before checking access.
The manufacturer lists a base weight of approximately 63kg. This is not the complete chair weight: batteries, seating and accessories must also be considered when arranging transport equipment.
The published UK configuration uses two 12V 62Ah deep-cycle batteries. The technical sheet lists an 8A off-board charger. Confirm the battery and charger supplied with your selected setup.
Yes. Available dimensions and seat heights depend on the seating package. Cushion thickness, powered functions and supports also affect the final sitting position, so confirm the complete setup during assessment.
This depends on the exact chair and seating configuration. Confirm occupied-transport approval and follow the instructions for securement points, wheelchair restraints and occupant restraints before travelling.
No. The Edge 3 Stretto is a separate model with a narrower base and different specifications. Compare the complete dimensions, seating options and handling of each chair before choosing.
